Time Range
The selectable range is �5 divisions by taking the center of the waveform area to be 0
divisions. The resolution is 0.01 divisions.
Threshold Level
You can set the threshold level in the following ways.
Auto The DL9000 automatically determines the threshold level from the peak-to-
peak or high-low value.
Level/Hys Set the values using the rotary knob.
Upper/Lower Set the values using the rotary knob.
* The threshold value is applied to a channel selected from CH1 to CH4 or from M1 to M4.
Notes about Automated Measurement of Waveform Parameters
• The DL9000 displays “*****” for values that cannot be measured.
• The DL9000 may not be able to measure correctly if the waveform amplitude is small.
• If there are two or more periods of the waveform in the time range, the DL9000
measures time measurement parameters (+Width, –Width, Period, Duty) on the first
period.
• T
o cancel automated measurement, turn the mode OFF
. Measurement will stop
immediately.
10.2 Performing Automated Measurement of Waveform Parameters
