10-35
IM 701310-01E
Analysis and Search
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
App
Index
Explanation
Analysis Type
• It analyzes XY, FFT, harmonics,
1
wave parameter, accumulated histogram, and serial
bus
2
items.
1 An optional power supply analysis function. See the option manual IM 701310-61E.
2 An optional serial bus analysis function. See the option manual IM 701310-51E.
Data Analyzed
The DL9000 can analyze the following data displayed on the screen.
• Waveform data
The DL9000 can analyze data any time regardless of whether or not it is acquiring
data. If acquiring signals, the DL9000 updates the analysis results in sync with the
displayed waveform.
The DL9000 can also analyze waveform data saved to the his
tory memory (the
waveform data at the record number selected using HISTOR
Y menu > Select).
• Loaded acquisition data (ACQ data)
10.5 Selecting the Analysis Type
To Next Page
