YOKOGAWA DL9040L User Manual

11-22
IM 701310-01E
Setting the Search Mode and Category
7.
Press these soft keys: Mode > Parameter.
This sets the search mode to Parameter.
8.
Press these soft keys: Category > Measure.
This sets the category to waveform parameter.
Selecting a Search Source
9.
Press the Item soft key.
10.
The menu that appears varies depending on the set waveform parameter mode
(see section 10.2 for details). Follow the instructions that correspond to the menu
that appears.
• If the mode is Basic, Continuous Statistics, or History Statistics, and you select Area 1 or
Area2, proceed to step 11.
• If the mode is Cycle Statistics and you select Basic, proceed to step 11.
• If the mode is Basic, Continuous Statistics, History Statistics, or Cycle Statistics and you
select Calc, proceed to step 13.
When the mode is Basic,
Continuous Statistics, or History
Statistics
When the mode is
Cycle Statistics
The Statistic menu appears
when the waveform
parameter mode is Cycle
Statistics .
You can choose a statistical
operation from Max, Min,
Mean, and σ.
The menu changes depending on the waveform parameter mode.
11.5 Searching History Waveforms Using Waveform Parameters (MEASURE History Search)
