Item Specifications
Trigger position Can be set in 0.1% increments of the display record length
Trigger delay By time: Delay for a specified time after the trigger condition is met
0 to 10 s, minimum resolution 5 ps (depending on the sample rate)
First edge after
delay:
Delay until the first specified edge after the specified time after the trigger
condition is met
0 to 10 s, resolution 2 ns
Edge Count: Delay until the specified number of specified edges after the trigger condition
is met
1 to 10E9, in steps of 1
Hold-off time setting range 20 ns to 10 s, resolution 5 ns
Trigger slope Rising or falling
Trigger type Edge/State
Edge: Activate a trigger on the edge of a single trigger source
Edge(Qualified): Activate a trigger on the edge of a single trigger source while the qualification
requirement is met
Edge OR: Activate a trigger on the logical OR of the edge conditions of multiple trigger
sources (max. 50 MHz)
State: Activate a trigger on the ENTER or EXIT condition when the state condition
is met
Width
Pulse: Activate a trigger on the width of a single trigger source
Pulse(Qualified): Activate a trigger on the width of a single trigger source while the qualification
requirement is met
Pulse State: Activate a trigger on the width when the state condition is met
Time width setting mode
More than: Activate a trigger when the condition changes when the time
during which the condition is met is longer than T1
Less than: Activate a trigger when the condition changes when the time
during which the condition is met is shorter than T1
Between: Activate a trigger when the condition changes when the
time during which the condition is met is longer than T1 and
shorter than T2
Out of Range: Activate a trigger when the condition changes when the time
during which the condition is met is shorter than T1 or longer
than T2
Time out: Activate a trigger when the time during which the condition is
met exceeds T1
Setting time (T1/T2): 1 ns to 10 s, resolution 500 ps resolution
Time accuracy: �(0.2% of setting value + 1 ns)
Event Interval
Event
:
Edge, Edge(Qualified), State, Pulse, Pulse(Qualified), Pulse State, Serial
pattern, I
2
C, CAN, LIN, SPI
(selectable as an event except TV, Edge OR, and UART)
Event Cycle: Activate a trigger when the event cycle is within the specified time range
Event Delay: Activate a trigger if the time interval between the event 1 occurrence and the
first event 2 occurrence is within the specified time range
Event Sequence: Activate a trigger when the first event 2 occurs within the specified time range
after the event 1 occurrence
Time width setting Same as the time width setting mode of Width
mode: Setting time (T1/T2): 1.5 ns to 10 s, resolution 500 ps
Time accuracy: �(0.2% of setting value + 1 ns)
Enhanced
TV: Trigger on video signal in various TV systems
Mode: NTSC, PAL, HDTV, USER
Input channel: CH1 to CH4
Sync Guard: 60-90% of Hsync, in steps of 1%
Line: 5 to 1054(NTSC), 2 to 1251(PAL), 2 to 1251(HDTV), 2 to
2048(USER)
Field: 1, 2, X
Frame Skip: 1, 2, 4, 8
Serial Pattern: Trigger on general-purpose serial communications signal
Maximum bit rate: 50 Mbps
Maximum bit length: 128 bits
19.3 Trigger Section
