2-34
IM 701310-01E
Saving and Loading Data from a Storage Medium â–ºFor the procedure, see
chapter 13
The DL9000 allows various data to be stored to and loaded from the following storage
media.
• PC card (standard equipment)
• External USB device (USB memory/MO disk drive/hard disk d
rive etc.)
• Network drive (when the Ethernet interface option is installed)
PC card
MO/Hard disk
drive, etc.
PC
DL9000
Saving and Loading Setting Data, Measurement Data, and Waveforms â–ºFor the
procedure, see sections 13.4 to 13.6
Setup data, measurement data, and snapshot/accumulated waveforms can be saved to
or loaded from a selected storage medium.
Saving Screen Image Data â–ºFor the procedure, see section 13.8
Screen image data can be stored to a selected storage medium. The formats that can be
saved are BMP, PNG, and JPEG and these can be used to incorporate the screen image
data in a document using DTP software.
Saving Analysis Results â–ºFor the procedure, see section 13.9
The values from automated measurement of waveform parameters, accum histogram,
FFT analysis, and analysis results of serial bus signal can be saved to a selected storage
medium.
2.10 Other Useful Functions
To Next Page
