Effects of Operating Conditions
The specifications below apply when the integration time is 16.67 ms or more.
Warm-up time: At least 30 minutes after power-up
Effects of ambient temperature:
The effect received by changes in 10°C increments of the ambient
temperature is
 ±(0.05%ofrdg+0.05%ofrange)orless
However,
±(0.2%ofrange+1digit)forCu10Ω
Effectsofpoweructuation:      
MeetstheaccuracyspecicationsforACpowersupplyinthe
range 90 to 132 V and 180 to 250 V
Effectsofmagneticeld:       
TheuctuationinexternalmagneticeldsforAC(50/60Hz)400
A/m is
 ±(0.1%ofrdg+10digits)orless
Effects from the signal source resistance:
EffectsonDCvoltageandthermocouplefromauctuationof1
kΩinthesignalsourceresistance
  DCvoltage: 1Vrangeorless ±10mVorless
   2Vrangeorhigher ±0.15%ofrdgorless
  Thermocouple:±10mVorless
  RTD: Fluctuationdueto10Ωchangepercable(same
resistanceforthethreewires);100Ωsystem:±0.1°
Corless,systemsotherthan100Ω:±1.0°Corless.
Fluctuation due to a difference in the resistance
betweenwiresof40mΩ(maximumdifference
among three wires) is approximately 0.1°C (for
Pt100)
Effect of position: Horizontal with the feet at the bottom is the rule.
Effectsofvibration: Theuctuationthatresultsbyapplyingasinusoidalvibration
along all three axis at a frequency between 10 to 60 Hz and an
acceleration of 0.2 m/s
2
is±(0.1%ofrdg+1digit)orless
External Dimensions
Unit: mm
57
131
150.8
Ifnotspecified,thetoleranceis±3%.However,incasesoflessthan10mm,the
toleranceis±0.3mm.
