27-8
SM80B22M02E
８． The multiplier of turn rate to output initial rudder order for starting turn.
The rudder angle has to be controlled larger than calculated value in order to increase rate of turn
at the starting of the turn during Track Control.
(This rudder angle is called the initial rudder angle.)
The output of initial rudder angle is decided by the multiplier and the setting rate due to ship’s
control parameter.
The multiplier to judge of output initial rudder angle can be set in this setting mode.
Present ROT(A) ≦ [Setting rate × multiplier](B)
If (A) value is (B) or less than (B) value, the initial rudder angle is output.
If (A) value is more than (B) value, the initial rudder angle is cot output and the rudder angle
calculated by ship’s control parameter.
Setting range : 0.00 to 9.99
Initial value : 0.70
【Caution】The [0.00] should not be set for this setting because the setting range is not checked.
（１）Press the
ENTER
ENTERENTER
ENTER
key after displayed "
Turning Chk=#.##
"on the data display.
Data display becomes current setting mode.
←Cursor position is inputting point
（２） Press
△
△△
△
+
++
+
or
▽
▽▽
▽
-
--
-
key to set the cursor point. Then change the data by turning the Set
course dial. Turn to the clockwise direction, data is increased and turn to the counter clockwise
direction, data is decreased. (Data is 0 to 9 numbers)
（３）After input the multiplier, then press
ENTER
ENTERENTER
ENTER
key.
To Next Page
