19-4
SM80B22M02E
7. Change the Min. time for alarm detection during one steering gear pump operation
(1)Press the
ENTER
ENTERENTER
ENTER
key after displayed "
Min.TimeS= ##s"
on the data display.
Data display become under setting mode.
Setting range: from 3 to 12
(Initial value is set 7 seconds)
Press
+
++
+
or
-
--
-
key to alter the Min. time for alarm detection during one steering
gear pump operation.
Press
ENTER
ENTERENTER
ENTER
key to set the Min time for alarm detection.
8.Change the Max. time for alarm detection during parallel steering gear pump operation
( For normal rudder angle:P/S Max.rudder order from 35 to 45degrees.)
(1)Press the
ENTER
ENTERENTER
ENTER
key after displayed "
Max.TimePN= ##s"
on the data display.
Data display become under setting mode.
Setting range: from 15 to 70
(Initial value is set 15 seconds)
Press
+
++
+
or
-
--
-
key to alter the Max. time for alarm detection during parallel steering
gear pump operation
Press
ENTER
ENTERENTER
ENTER
key to set the Max time for alarm detection.
9.Change the Max. time for alarm detection during pararelle steering gear pump operation
(For wide rudder angle: P/S Max. rudder order from70 to 210 degrees)
(1)Press the
ENTER
ENTERENTER
ENTER
key after displayed "
Max.TimePW= ###s"
on the data display.
Data display become under setting mode.
Setting range: from 15 to 160
(Initial value is set 15 seconds)
Press
+
++
+
or
-
--
-
key to alter the Max. time for alarm detection during pararelle steering
gear pump operation
Press
ENTER
ENTERENTER
ENTER
key to set the Max time for alarm detection.
10. Change the Min. time for alarm detection during parallel steering gear pump operation
(1Press the
ENTER
ENTERENTER
ENTER
key after displayed "
Min.TimeP= ##s"
on the data display.
Data display become under setting mode.
Setting range: from 3 to 12
(Initial value is set 4 seconds)
Press
+
++
+
or
-
--
-
key to alter the Min.time for alarm detection during parallel steering
gear pump operation
Press
ENTER
ENTERENTER
ENTER
key to set the Max time for alarm detection.
Servo Loop Err.
Min.TimeS< # #s
Servo Loop Err.
Max.TimePN< # #s
Servo Loop Err.
Max.TimePW< # # #s
Servo Loop Err.
Min.TimeP< # #s
