19-3
SM80B22M02E
angle.
Press ENTER
ENTERENTER
ENTER key to set the Max. rudder angle.
４．Change the Max. rudder angle for alarm detection of the variation angle
(For wide rudder angle: P/S Max. rudder order from70 to 210 degrees)
（１）Press the ENTER
ENTERENTER
ENTER key after displayed "
Max.AngleW= # #ˆ "on the data display.
Data display become under setting mode.
Setting range: from 70 to 210
(Initial value is set 70 degrees)
（２）Press △
△△
△ +
++
+ or ▽
▽▽
▽ -
--
- key to alter the Max. rudder angle for alarm detection of the variation
angle.
Press ENTER
ENTERENTER
ENTER key to set the Max. rudder angle.
５．Change the Max. time for alarm detection during one steering gear pump operation
( For normal rudder angle:P/S Max.rudder order from 35 to 45degrees.)
（１）Press the ENTER
ENTERENTER
ENTER key after displayed "
Max.TimeSN= ##s" on the data display.
Data display become under setting mode.
Setting range: from 15 to 70
(Initial value is set 30 seconds)
（２）Press △
△△
△ +
++
+ or ▽
▽▽
▽ -
--
- key to alter the Max. time for alarm detection during one steering
gear pump angle.
Press ENTER
ENTERENTER
ENTER key to set the Max. time for alarm detection.
６．Change the Max. time for alarm detection during one steering gear pump operation
(For wide rudder angle: P/S Max. rudder order from70 to 210 degrees)
（１）Press the ENTER
ENTERENTER
ENTER key after displayed " Max.TimeSW= ###s" on the data display.
Data display become under setting mode.
Setting range: from 15 to 160
(Initial value is set 30 seconds)
（２）Press △
△△
△ +
++
+ or ▽
▽▽
▽ -
--
- key to alter the Max. time for alarm detection during one steering
gear pump operation.
Press ENTER
ENTERENTER
ENTER key to set the Max. time for alarm detection.
Servo Loop Err.
…
Max.AngleW< # # #ˆ
Servo Loop Err.
…
Max.TimeSN< # # #s
Servo Loop Err.
…
Max.TimeSW< # # #s
