ZCube-21 User Guide
DOC-USR-0253-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8
th
ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
downloaded is required. Please see Section 8.0, Decode Options, for more
information on compatible decoders and PC configuration and requirements for H.265/HEVC decode at 4K
resolutions.
5.1 Stream UDP
5.1.1 UDP Camera Setup
Note: Settings in the user interface cannot be changed if the unit is currently encoding.
(1) If necessary, click on the Stop button in the Channel Controls section of the user interface CH1 tab
or the Stop All button in the lower right corner of the screen of any tab.
(2) Verify the Output Resolution is set to Follow Input to output a 4K stream. If a lower resolution
output is desired, select this in the dropdown menu and resizing will occur.
(3) Select the Video Codec you would like to use for your video encoding. In the pictured example
H265(HEVC) is selected.
(4) Under Output Setup, select UDP in the Output Format dropdown menu.
(5) Set Dest Address to:
a. the IP address of your PC that will be running the VLC media player. To determine the
correct IP address of your PC, see APPENDIX A: Finding the IP Address of Your Computer. In
the example pictured, 192.168.0.6 is used.
b. or a multicast address. An example multicast address would be 225.1.2.3. If you are on a
shared network, check with your Network Administrator.
(6) Make note of the value listed for Dest Port. This will be 8600 by default when your system is first
received.
Note: By default a limited selection of video encoding settings are available in the user interface. See Section
7.2, “Advanced Settings Mode”, for more information on accessing additional settings.
(7) Click on the Start button. After a moment, the encoder status will change to RUNNING and the
fields above will appear in dark grey. The status LED on the unit will blink green when streaming.
