9.6 The CH2 & CH3 Tabs (Channels 2 & 3)
The ZCube-21 supports simultaneous encode into multiple different resolutions and bit rates. Each output
stream can be set using a separate Channel tab. See the CH1 Tab section for detailed descriptions of
available settings on the CH2 and CH3 tab. If these tabs are not present, you can create a them by clicking
on the “+” tab. Only three channels are supported.
The maximum performance for two channels is one 2160p30 plus one 720p30 stream.
CH2 Default:
Parameter
Options (default in bold)
Description
Encoder Setup
Output Resolution
320x180 – 12560x1440
(1280x720)
Follow Input
The encode resolution. If this resolution is different
from the capture resolution (3840x2160), resizing
will occur.
Video Bitrate
2K – 40M (2M)
Textbox for entering video bit rate.
CH3 Defaults:
Parameter
Options (default in bold)
Description
Encoder Setup
Output Resolution
320x180 – 2560x1440
(720-480)
Follow Input
The encode resolution. If this resolution is different
from the capture resolution (3840x2160), resizing
will occur.
Video Bitrate
2K – 100M (2M)
Textbox for entering video bit rate.
9.7 Values Appearing at the Bottom of All Tabs
Parameter
Options (default in bold italics)
Description
preset
encoder
(any user-defined profiles)
--- new preset ---
The configuration file selected for use.
encoder: Factory default settings
Can also add more profiles by selecting --- new
preset ---.
