ZCube-21 User Guide
DOC-USR-0253-01
______________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8
th
ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
60
Top Center
Top Right
Bottom Left
Bottom Center
Bottom Right
Overlay Text Size
16 px
32 px
64 px
Sets size of display text in pixels.
Channel Controls
Stop Button
Stop current encode session for Channel 1. Encode
must be stopped in order for settings to be altered.
Start Button
Start encode session for Channel 1.
Delete Button
Removes channel instance for encoding.
status
!Not running, IDLE,
STOPPED, RUNNING,
POLLING
Current status of the encode process.
IDLE indicates no valid input data is present.
STOPPED indicates that the unit is not currently
encoding. Must be in this mode to make any
configuration changes.
POLLING indicates “start” was pressed and the
encoder is waiting for valid input data to be
detected.
RUNNING indicates the unit is currently encoding.
Error statuses will be preceded by an exclamation
point and include a description of the error.
Note 1: Encode Resolutions Supported:
2160p (8MP), 1440p (4MP), 1080p (2MP), 1280x1024, 720p (1MP), 480p, 576p, 1024x576, 704x576,
640x480, 640x360, 420x380, 352x576, 352x288, 352x240, 320x240, and 320x180
Follow input
“Follow input” = Generate encoder resolution based on capture resolution detected
