ZCube-21 User Guide

DOC-USR-0253-01

______________________________________________________________________________________

Z3 Technology, LLC ♦ 100 N 8

ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702

Figure 4 CH1 Tab Configuration – UDP

(4) Change

to “UDP”

(1) If necessary, click “Stop”

(7) Click “Start”

(2) Verify is

“Follow input”

(3) Verify is

“H265(HEVC)”

(5) Set to PC

IP Address or

Multicast Address

(6) Note value
