export
Export current settings to a file.
import
Load settings from a previously exported file.
Reset
Resets presets.
9.3 The Status Tab
The Status tab may take a few seconds to load after being clicked.
Output Value
Explanation
Video Status
CH
The channel number (1 - 3)
Bitrate (Kbps)
Current target bit rate of encoder
Actual Bitrate
Actual bit rate being output by encoder
FPS
Current target frames per second of encoder
Actual FPS
Actual frames per second being encoded
Key-frame FPS
# of key-frames per second (for example, a value of 0.5 means a key
frame is inserted every two seconds)
Width
Width of encoded picture
Height
Height of encoded picture. A small “i” will appear if interlaced is being
encoded.
Audio Status
Channel
The channel number (1 - 3)
Codec
The codec being used to encode audio for that channel
Frames
Number of frames sent from encoder to channel since the beginning of
encoding.
Stream Status
Channel
The channel number (1 - 3)
URL
URL the channel is being streamed to
Frames
Number of frames sent from encoder to channel since the beginning of
encoding. This can serve as a quick sanity check. (For example, you can
click “Refresh”, count to 10, click “Refresh” again, and you should see an
increase of around 600 for 60 frames per second content).
Input Status
Input
HDMI1 refers to the captured content from the camera lens
Resolution
Capture resolution for video
