ZCube-21 User Guide

DOC-USR-0253-01

______________________________________________________________________________________

Z3 Technology, LLC ♦ 100 N 8

ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702

Figure 23 VLC Media Player Advanced Preferences

5.4.5 Recommended Settings:

When streaming 4K video in HEVC/H.265 mode, the following recommended settings can be used

for the best results:

Output

Format

Rate

Control

Bitrate

VLC Network

Cache

Notes

RTSP

CBR

4 Mbps

300 ms

Best latency (approx. 400 ms), no frame skips

TSRTP

CBR

5 Mbps

1000 ms

@ 300 ms, frame skips; @ 1000 ms, no frame skips

UDP

CBR

5 Mbps

1000 ms

@ 300 ms, frame skips; @ 1000 ms, no frame skips

Figure 24 Recommended Settings
