1.0 GENERAL DESCRIPTION

The ZCube-21 is a H.265/HEVC, H.264 and MJPEG video encoder designed for easy and portable use. It is

capable of accepting 4K video at 30 frames per second and producing IP streams that can be sent on a

standard Ethernet cable.

Figure 1 ZCube-21 Board Stack Dimensions
