8.1.3 LAV Filters

(1) Install LAV Filters if necessary.

(2) Navigate to the Properties and select the Video Settings tab.

(3) Verify the HEVC checkbox is checked under Codecs for HW Decoding.

(4) Enable the Nvidia video card under Hardware Decoder to use.

(5) Select Apply.

Figure 43 LAV Filters Configuration

Verify is Set

to your Nvidia

video card

Verify

“HEVC” is

checked
