destination. This can be fixed by increasing the TTL by adding /NN after the multicast

address within our Web Interface. (NN is a two-digit number).

Ex: 239.0.12.33/10 equals a TTL of 10 hops the max value that can be defined as 255.

(6) Press Enter or click Play. You will see your camera’s video streaming to VLC.

Note: RTSP is only supported with VLC version 2.1.5 or later. When encoding via RTSP, any time the encoding

session is stopped and restarted, you will need to reopen VLC in order to view the stream.

Figure 13 Example of Z3 Video Streaming to VLC (RTSP)
