Type
Absolute
Relative
Type of PTZ control expected.
Flip
None
Flip Pan Axis
Flip Tilt Axis
Flip Pan & Tilt
Flips Axis for PT Controls
Position
Most Recent Command
Query Device
Software can be set to use either the position after
the most recent comment or to query the device
each time.
Max Tilt
90 degrees
100 degrees
180 degrees
Sets the maximum tilt of the device
Video Source
Video source from CHX tab
ONVIF Token
ONVIF token ID
ONVIF Name
Setable ONVIF name
Enabled
Enable/Disable PTZ
RS485 Address
RS485 Address
TCP Port
TCP port used for remote terminal server
DOC-USR-0255-XX_Qualcomm_PTZ_App_Note.pdf explains how to set up the hardware for PTZ
operations.
9.5 The CH1 Tab (Channel 1)
An asterisk (*) denotes a field available in Advanced Settings Mode. See Section 7.2 to access these fields.
Parameter
Options (default in bold)
Description
Encoder Setup
Output Resolution
320x180 – 2560x1440
Follow Input
The encode resolution. If this resolution is different
from the capture resolution (3840x2160), resizing
will occur. Follow Input generates the resolution
based on the capture resolution. [Note 1]
Video Codec
H265(HEVC)
H264(AVC)
Selects the codec used for compression of the
output video stream.
