the RS-485 (PTZ) functionality.
The Term tab contains two tables one of available serial ports and one of available PTZ control.
Parameter
Options (default in bold)
Description
Serial Port Configuration
Serial Port
RS-232 port
RS-485 port
RS-232 console port
/dev/ttyHS2
/dev/ttyHS1
/dev/ttyMSM0
Baud Rate
1200
2400
9600
19200
38400
57600
115200
Each serial port can be configured with a selected
baud rate.
Data Bits
5
6
7
8
Sets the number of data bits sent per serial
message, most serial devices expect 8 data bits.
Parity
None
Odd
Even
Sets serial parity for serial ports. Most devices
expect none.
Stop Bits
1
2
Sets number of stop bits for serial port. Most
devices expect 1.
Function
Camera 1 (VISCA)
Off
User
Console
RS485(PTZ)
Sets the function of the serial port.
TCP Port
TCP port used for remote terminal server.
PTZ Configuration
