Error code
Effect
Condition
Restart
procedure
MDI /
LED
CODE
CAN
OPEN
CODE
ZAPI
CODE
STALL ROTOR
Traction/Pump stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
11
FFD3
211
CONTROLLER MISM.
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up
Install the correct
software and Key
re-cycle
12
FFEF
239
EEPROM KO
Controller works using default
parameters
Start-up, stand-by,
running
13
3610
208
PARAM RESTORE
No effect
Start-up
Traction/Pump
request
14
0
209
HW FAULT EV.
MC is not closed, EB is applied,
Traction/Pump stopped
Start-up
Key re-cycle
16
FFEE
238
LOGIC FAILURE #3
MC is opened, EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by
Valves or
Traction/Pump
request
17
FF11
17
LOGIC FAILURE #2
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by,
Valves or
Traction/Pump
request
18
FF12
18
LOGIC FAILURE #1
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Stand-by, running
Valves or
Traction/Pump
request
19
5114
19
VKEY OFF SHORTED
MC is not closed, EB is applied,
Traction/Pump stopped
Start-up
Key re-cycle
20
5101
220
CONT. DRV. EV
Valves stopped
Start-up, stand-by,
running
Valves request
21
FFE8
232
DRV. SHOR. EV
Valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
21
FFF9
234
OPEN COIL EV.
MC remains closed, EB is
applied, Traction/Pump, valves
stopped (the command is
released)
Start-up, Stand-by,
running
Valves or
Traction/Pump
Request
21
FFF2
242
LC COIL OPEN
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
22
FFE6
230
IQ MISMATCHED
Traction is stopped, MC is opened
Running
Valves or
Traction/Pump
request
24
FFF5
245
PEB NOT OK
Pump motor stopped, valves
stopped
Start-up, stand-by,
running
Valves request
25
FFDB
217
AUX BATT. SHORT.
None
Start-up, stand-by,
running
27
5001
194
INIT VMN LOW
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up
Valves or
Traction/Pump
request
30
3121
207
VMN LOW
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up
Valves or
Traction/Pump
request
30
3120
30
INIT VMN HIGH
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up
Valves or
Traction/Pump
request
31
3111
206
VMN HIGH
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by
Valves or
Traction/Pump
request
31
3110
31
HW FAULT
MC is not closed, EB is applied,
Traction/Pump stopped
Start-up
Key re-cycle
32
FFE3
227
HW FAULT EB.
MC is opened, EB is applied,
Traction/Pump stopped
Start-up
Key re-cycle
34
FFE5
229
POSITIVE LC OPEN
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
35
FFD5
213
FIELD ORIENT. KO
MC is opened, EB is applied,
Traction/Pump, valves stopped
Running
Valves or
Traction/Pump
request
36
FFFD
253
CONTACTOR CLOSED
MC is not closed (command is not
activated), EB is applied,
Traction/Pump stopped
Start-up
Valves or
Traction/Pump
request
37
5442
37
CONTACTOR OPEN
MC is opened, EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
38
5441
38
POWER MISMATCH
Traction is stopped, EB is applied,
MC is opened
Running
Traction/Pump
request
39
FFD4
212
EB. DRIV.SHRT.
MC remains closed, EB is applied
(the command is released),
Traction/Pump, valves stopped
Stand-by, running
Valves or
Traction/Pump
Request
40
3222
254
WRONG SET BAT.
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up
41
3100
251
WRONG KEY VOLT.
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up
41
3101
170
