AFNZPxxx– DUALACE2 NEW GENERATION – User Manual Page 125/169
Error code
Effect
Condition
Restart
procedure
MDI /
LED
CODE
CAN
OPEN
CODE
ZAPI
CODE
EB. DRIV.OPEN
MC remains closed, EB is applied
(the command is released),
Traction/Pump, valves stopped
Running
Valves or
Traction/Pump
Request
42
3224
246
EB. COIL OPEN
MC remains closed, EB is applied
(the command is released),
Traction/Pump, valves stopped
Start-up, Stand-by,
running
Valves or
Traction/Pump
Request
43
FFD8
216
HANDBRAKE
Traction/Pump motor is stopped
Start-up, stand-by,
running
Traction/Pump
request
46
FFDD
221
MOT.PHASE SH.
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up
Traction/Pump
request
47
FFC4
196
THROTTLE PR‚
MC remains closed, EB is applied
(the command is released),
Traction stopped
Start-up, Stand-by,
running
Valves or
Traction/Pump
Request
48
FFF3
243
LIFT+LOWER
Pump is stopped
Start-up, stand-by,
running
Pump request
49
FFBB
187
TILLER OPEN
LC opens
Start-up, stand-by,
running
Valves or
Traction/Pump
Request
51
0
228
STBY I HIGH
MC is not closed, EB is applied,
Traction/Pump stopped
Start-up, stand-by
Valves or
Traction/Pump
request
53
2311
53
OVERLOAD
MC is not closed, EB is applied,
Traction/Pump stopped
Running
Valves or
Traction/Pump
request
57
FFB4
180
CAPACITOR CHARGE
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up
Valves or
Traction/Pump
request
60
3130
60
THERMIC SENS. KO
Maximum current is reduced
according to parameter MOT.T.
T.CUTBACK and speed is
reduced to a fixed value.
Start-up, stand-by,
running
61
4211
250
TH. PROTECTION
Traction controller reduces the
max current linearly from Imax
(85°C) down to 0 A (105°C)
Start-up, stand-by,
running
62
4210
62
BRAKE RUN OUT
Traction is stopped
Start-up, stand-by,
running
Traction/Pump
Request
63
FFCC
204
TILLER ERROR
Traction stopped, EB applied
Stand-by, running
Valves or
Traction/Pump
Request
64
FFB9
185
MOTOR TEMPERAT.
Maximum current is linearly
reduced (see paragraph 9.15) and
speed is reduced to a fixed value.
Start-up, stand-by,
running
65
4110
65
MOTOR TEMP. STOP
EB is applied, Traction/Pump,
valves stopped
Start-up, stand-by,
running
65
FFB2
178
NO CAN MSG.
MC is opened, EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
67
8130
248
SENS MOT TEMP KO
Maximum current is reduced
according to parameter MOT.T.
T.CUTBACK and speed is
reduced to a fixed value.
Start-up, stand-by,
running
68
4311
218
SMARTDRIVER KO
MC is not closed, Traction/Pump,
valves stopped
Start-up
Key re-cycle
69
3302
193
EPS RELAY OPEN
Traction/Pump motor is stopped
Start-up, stand-by,
Running
Valves or
Traction/Pump
request
70
FFCD
205
WRONG RAM MEM.
MC is opened, EB is applied,
Traction/Pump, valves stopped
Stand-by
Key re-cycle
71
FFD2
210
DRIVER SHORTED
MC is opened (the command is
released), EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
74
3211
74
CONTACTOR DRIVER
MC is opened (the command is
released), EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
75
3221
75
COIL SHOR. MC
MC is opened, EB is applied,
Traction/Pump, valves stopped
Start-up
(immediately after
MC closing), stand-
by, running
Valves or
Traction/Pump
request
76
2250
223
VDC LINK OVERV.
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Stand-by, running
Valves or
Traction/Pump
request
77
FFCA
202
VACC NOT OK
Traction/Pump motor is stopped
Start-up, stand-by,
running
Traction/ request
78
FF4E
78
INCORRECT START
Traction/Pump motor is stopped
Start-up, stand-by
Traction request
79
FF4F
79
PUMP INC START
Pump motor is stopped
Start-up, stand-by,
running
Pump request
79
FFBD
189
FORW + BACK
Traction is stopped
Start-up, stand-by,
running
Traction request
80
FF50
80
SPEED FB. ERROR
MC is opened , EB is applied,
EVP stopped
Running
Valves or
Traction/Pump
request
81
FFAF
175
