Zapi DUALACE2 NEW GENERATION User Manual

Page 88/169 AFNZPxxx – DUALACE2 NEW GENERATION – User Manual
ADJUSTMENTS
Parameter
Allowable range
Description
MC VOLTAGE
(A)
0% ÷ 100%
(steps of 1%)
This parameter specifies the duty-cycle (t
ON
/T
PWM
) of the
PWM applied to the main-contactor output A26 (A16)
during the first second after the activation signal that
causes the main contactor to close.
MC VOLTAGE RED.
(A)
0% ÷ 100%
(steps of 1%)
This parameter defines a percentage of MC VOLTAGE
parameter and it determines the duty-cycle applied after
the first second of activation of the contactor.
For details and examples see paragraph 0.
EB VOLTAGE
(A)
0% ÷ 100%
(steps of 1%)
This parameter specifies the duty-cycle (t
ON
/T
PWM
) of the
PWM applied to the electromechanical brake output A28
(A18) during the first second after the activation signal that
causes the electromechanical brake to release.
EB VOLTAGE RED.
(A)
0% ÷ 100%
(steps of 1%)
This parameter defines a percentage of EB VOLTAGE
parameter and it determines the duty-cycle applied after
the first second since when the electromechanical brake is
released.
For details and examples see paragraph 0.
MAX. MOTOR TEMP.
(A)
60°C ÷ 175°C
(steps of 1°C)
This parameter defines the motor temperature above
which a 50% cutback is applied to the maximum current.
Cutback is valid only during motoring, while during braking
the 100% of the maximum current is always available
independently by the temperature.
TEMP. MOT. STOP
(A)
60°C ÷ 190°C
(steps of 1°C)
This parameter defines the maximum motor temperature
permitted, above which the controller stops driving the
motor.
DIAG.JUMP SENS
(A)
0-255Hz
This parameter defines the maximum jump admitted for
the feedback sensor of motor 1 above which the controller
stops driving the motor rising an alarm.
S DIAG.JUMP SENS
(A)
0-255Hz
This parameter defines the maximum jump admitted for
the feedback sensor of motor 2 above which the controller
stops driving the motor rising an alarm.
A.SENS.MAX SE
(Only for BLE version
with sin/cos sensor)
(A)
Volt
This parameter records the maximum offset voltage at the
sine analog input during the auto-teaching procedure.
It can be compared with the A.SENS.OFFSET SR entry
value.
A.SENS.MIN SE
(Only for BL version
with sin/cos sensor)
(A)
Volt
This parameter records the minimum offset voltage at the
sine analog input during the auto-teaching procedure.
It can be compared with the A.SENS.OFFSET SR entry
value.
A.SENS.MAX CE
(Only for BLE version)
(A)
Volt
This parameter records the maximum offset voltage at the
cosine analog input during the auto-teaching procedure.
It can be compared with the A.SENS.OFFSET CR entry
value.
