SPECIAL ADJUSTMENTS
Parameter
Allowable range
Description
DUTY PWM CTRAP
(Read Only)
(A)
0% ÷ 100%
This parameter defines the duty cycle for overcurrent
threshold. Reserved.
PWM AT LOW FREQ
(A)
This parameter defines the power-bridge PWM frequency at
low speed.
NOTE: only Zapi technicians can change this value through
a special procedure.
PWM AT HIGH FREQ
(A)
This parameter defines the power-bridge PWM frequency at
high speed.
NOTE: only Zapi technicians can change this value through
a special procedure.
FREQ TO SWITCH
(A)
Volt
(Factory adjusted). This parameter defines the electrical
frequency at which the switching frequency is changed from
PWM AT LOW FREQ to PWM AT HIGH FREQ.
HIGH ADDRESS
(A)
0 ÷ 4
This parameter is used to access special memory
addresses.
CAN BUS SPEED
(A)
20 kbps ÷ 500 kbps
This parameter defines the CAN bus data-rate in kbps.
20, 50, 125, 250, 500
EXTENDED FORMAT
(A)
OFF, ON
This parameter defines the CAN bus protocol.
DEBUG CANMESSAGE
(A)
OFF, ON
This parameter enables or disables special debug
messages.
CONTROLLER TYPE
(A)
0 ÷ 3
This parameter defines the controller type:
Dual Traction wired
Combi wired
Dual OPEN CAN
Combi OPEN CAN
NOTE: a mismatch between this parameter and the
hardware configuration may lead to a severe malfunctioning
of the controller.
MOTOR TYPE M
(A)
0 ÷ 1
This parameter defines the motor 1 type:
AC Motor: AC induction motor
BL Motor: permanent magnet synchronous motor
MOTOR TYPE S
(A)
0 ÷ 1
This parameter defines the motor 1 type:
AC Motor: AC induction motor
BL Motor: permanent magnet synchronous motor
