Standard Parameter Defaults A - 5
Image Capture Illumination 361 F0h 69h Enable
6-5
Image Capture Autoexposure 360 F0h 68h Enable
6-5
Fixed Exposure 567 F4h F1h 37h 100
6-6
Fixed Gain 568 F1h 38h 50
6-6
Gain / Exposure Priority for Snapshot
Mode
562 F1h 32h Autodetect
6-7
Snapshot Mode Timeout 323 F0h 43h 0 (30 seconds)
6-8
Snapshot Aiming Pattern 300 F0h 2Ch Enable
6-9
Silence Operational Mode Changes 1293 F8h 05h 0Dh Disable (do not silence)
6-9
Image Cropping 301 F0h 2Dh Disable
6-10
Crop to Pixel Addresses 315
316
317
318
F4h F0h 3Bh
F4h F0h 3Ch
F4h F0h 3Dh
F4h F0h 3Eh
0 top
0 left
959 bottom
1279 right
6-11
Image Size (Number of Pixels) 302 F0h 2Eh Full
6-12
Image Brightness (Target White) 390 F0h 86h 180
6-13
JPEG Image Options 299 F0h 2Bh Quality
6-13
JPEG Target File Size 561 F1h 31h 160 kB
6-14
JPEG Quality and Size Value 305 F0h 31h 65
6-14
Image Enhancement 564 F1h 34h Low (1)
6-15
Image File Format Selector 304 F0h 30h JPEG
6-16
Image Rotation 665 F1h 99h 0
6-17
Bits per Pixel (BPP) 303 F0h 2Fh 8 BPP
6-18
Signature Capture 93 5Dh Disable
6-19
Signature Capture Image File Format
Selector
313 F0h 39h JPEG
6-20
Signature Capture Bits per Pixel
(BPP)
314 F0h 3Ah 8 BPP
6-21
Signature Capture Width 366 F4h F0h 6Eh 400
6-22
Signature Capture Height 367 F4h F0h 6Fh 100
6-22
Signature Capture JPEG Quality 421 F0h A5h 65
6-22
Table A-1 Parameter Defaults (Continued)
