Zebra DS8178 Product Reference Guide

A - 4 DS8178 Digital Scanner Product Reference Guide
Hands-Free Decode Session Timeout 400 F0h 90h 15 5-27
Timeout Between Decodes, Same
Symbol
137 89h 0.5 sec 5-28
Timeout Between Decodes, Different
Symbols
144 90h 0.1 sec 5-28
Triggered Timeout, Same Symbol 724 F1 D4 Disable 5-29
Decode Mirror Images (Data Matrix
Only)
537 F1h 19h Auto 5-30
Mobile Phone/Display Mode 716 F1h CCh Normal 5-31
PDF Prioritization 719 F1h CFh Disable 5-32
PDF Prioritization Timeout 720 F1h D0h 200 ms 5-33
Presentation Mode Field of View 609 F1h 61h Full 5-33
Decoding Illumination 298 F0h 2Ah Enable 5-34
Motion Tolerance (Hand-Held Trigger
Mode Only)
858 F2h 5Ah Less Motion Tolerance 5-34
Add an Enter Key N/A N/A N/A 5-36
Transmit Code ID Character 45 2Dh None 5-36
Battery Threshold
Battery Status High Threshold
Battery Status Medium Threshold
Battery Status Low Warning
Threshold
Battery Health Low Warning
Threshold
1367
1368
1369
1370
N/A
50%
20%
10%
60%
5-35
Prefix Value 99, 105 63h, 69h 7013 <CR><LF> 5-38
Suffix 1 Value
Suffix 2 Value
98, 104
100, 106
62h, 68h
64h, 6Ah
7013 <CR><LF> 5-38
Scan Data Transmission Format 235 EBh Data as is 5-39
FN1 Substitution Values 103, 109 67h, 6Dh 7013 <CR><LF> 5-40
Transmit “No Read” Message 94 5Eh Disable 5-41
Unsolicited Heartbeat Interval 1118 F8h 04h 5Eh Disable 5-42
Imaging Preferences
Operational Modes N/A N/A N/A 6-4
Table A-1 Parameter Defaults (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number

Zebra DS8178 Specifications

General

Product color	Black
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Photo diode
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Optical sensor resolution	1280 pixels
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
PC connection	RS-232/USB
Wireless range	100 m
Bluetooth version	4.0
Standard interfaces	USB, RS-232, Bluetooth
Connectivity technology	Wired & Wireless
Battery life	83 h
Battery capacity	2500 mAh
Power source type	Battery

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	235.3 g
