Zebra FX7500 Integrator Guide

A - 2 FX7500 RFID Reader Integrator Guide
KT-FX75002WR-01 2-Port Global Reader Kit
• FX7500-22315A30-US (2-port global reader)
• AN480-CL66100WR (wide-band AN-480 antenna)
• BRKT-70661-01R (antenna mounting bracket)
• CBLRD-1B4001800R (15-foot RF cable)
• 50-14000-159R (power supply)
Technical Specifications
The following tables summarize the RFID reader intended operating environment and technical hardware
specifications.
Table A-1 Technical Specifications
Item FX
Physical and Environmental Characteristics
Dimensions 7.7 in. L x 5.9 in. W x 1.7 in. D
(19.56 cm L x 14.99 cm W x 4.32 cm D)
Weight 1.9 lbs ± 0.1 lbs (0.86 kg +/- 0.05 kg)
Base Material Die cast aluminum, sheet metal and plastic
Visual Status Indicators Multi-color LEDs: Power, Activity, Status, and Applications
Mounting Keyhole and standard VESA (75 mm x 75 mm)
FX Environmental Specifications
Operational Temperature -4° to +131° F / -20° to +55° C
Storage Temperature -40° to +158° F / -40° to +70° C
Humidity 5 to 95% non-condensing
Shock and Vibration MIL-STD-810G
Connectivity
Communications 10/100 BaseT Ethernet (RJ45) w/ POE support
USB Client (Type B), USB Host (Type A)
General Purpose I/O 2 inputs, 3 outputs, optically isolated (terminal block)
External 12V ~ 48 VDC power available for GPIO
Power POE or POE+
12 VDC to 48 VDC, or 24 VDC Universal Power Supply
Antenna Ports FX 7500-2: 2 mono-static ports (reverse polarity TNC)
FX 7500-4: 4 mono-static ports (reverse polarity TNC)

Zebra FX7500 Specifications

General

Interface	USB
Product color	White
LED indicators	Activity, Power, Status
Housing material	Aluminium, Metal, Plastic
Battery type	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84719000

Weight and Dimensions

Depth	43.2 mm
Width	149.9 mm
Height	195.6 mm
Weight	860 g
