Zebra FX7500 Integrator Guide

CHAPTER 4 ADMINISTRATOR CONSOLE
Introduction
This chapter describes the FX7500 Reader Administrator Console functions and procedures. Access the
Administrator Console using a web browser from a host computer, and use this to manage and configure the
readers. The
Administrator Console main window and support windows have four areas, each containing
unique information about the reader.
• Selection Menu - selects the function for the primary information window.
• Primary Information Window - provides the primary function information.
• Product Identification Header - identifies the product.
• USB Port Status - provides details on the USB device connected to the USB host port. Hover the mouse
pointer over the blue link, available only when a device is detected.
• Help Information Window:
• provides detailed information to support the primary information window
• includes a scroll bar to scroll through information
• includes a toggle button to turn on/off the help information window
NOTE The screens and windows in this chapter may differ from actual screens and windows. The applications
described may not be available on (or applicable to) all devices. Procedures are not device-specific and
are intended to provide a functional overview.

Zebra FX7500 Specifications

General

Interface	USB
Product color	White
LED indicators	Activity, Power, Status
Housing material	Aluminium, Metal, Plastic
Battery type	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84719000

Weight and Dimensions

Depth	43.2 mm
Width	149.9 mm
Height	195.6 mm
Weight	860 g
