Zebra FX7500 Integrator Guide

CHAPTER 5 WI-FI CONFIGURATION
Wireless Network Advanced Configuration
FX7500 uses the wpa_supplicant application to connect with wireless networks. Advanced users can place
their own configuration file in the /apps folder to connect to wireless networks. This configuration file is
wpa_supplicant.conf. The parameters of this file are well documented in the public domain. Refer to
http://linux.die.net/man/5/wpa_supplicant.conf for the most commonly used parameters and
http://www.daemon-systems.org/man/wpa_supplicant.conf.5.html for all available parameters. Also see
Appendix E, Copying Files To and From the Reader for instructions on copying files to /apps directory.
If /apps/wpa_supplicant.conf is present in the reader, the reader uses this file to connect to a wireless
network. This supersedes the configuration in the Administrator Console, which changes to reflect the
custom configuration file.
Figure 5-1 Administrator Console Update

Zebra FX7500 Specifications

General

Interface	USB
Product color	White
LED indicators	Activity, Power, Status
Housing material	Aluminium, Metal, Plastic
Battery type	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84719000

Weight and Dimensions

Depth	43.2 mm
Width	149.9 mm
Height	195.6 mm
Weight	860 g
