4 - 20 FX7500 RFID Reader Integrator Guide
Communication Standard - Select the communication standard from the list of standards that the chosen
region supports. If a region supports only one standard, it is automatically selected.
Frequency Hopping - Check to select frequency hopping. This option appears only if the chosen region of
operation supports this.
Selected Channels - Select a subset of channels on which to operate (from the list of supported
channels). This option appears only if the chosen region of operation supports this.
Please confirm - Check the I understand check box to confirm your understanding that the choices are in
compliance with local regulatory requirements.
Set Properties - Click to apply the changes. Select Commit/Discard on page 4-45 to save the changes to
the reader.
Certificates
You can protect network services on the reader using SSL/TLS to secure the communication channel against
eavesdropping or tampering, and optionally authenticate peer networked nodes involved in the
communication. SSL/TLS protocol uses Public Key Infrastructure digital certificates. The following services on
the reader support SSL/TLS:
Web Administrator Console service (HTTPS). See Network Services Settings on page 4-37.
File Transfer Service (FTPS - explicit SSL/TLS over FTP). See Network Services Settings on page 4-37.
Shell Service (SSH - by default always in secure mode).
Secure LLRP Service (refer to the EPC Global LLRP Standard, Security in TCP Transport). See the
Enable Secure Mode option in Configure LLRP Settings on page 4-34.
NOTE The supported version of SSL/TLS varies between services. Different services support SSL v3 and TLS
1.0 and above.
NOTE The Validate Peer option in Secure LLRP Service configuration enables authentication of reader and/or
clients using digital certificates. You must import a custom certificate (instead of the default self-signed
certificate) to the reader to enable this option. See Configure LLRP Settings on page 4-34 for details.
Services other than Secure LLRP rely on password-based authentication.
NOTE The SNMP service on the reader supports SNMP v2c and does not support security.
