Zebra FX7500 Integrator Guide

1 - 6 FX7500 RFID Reader Integrator Guide
Step 5, Read Tags
Select Read Tags to view the Reader Operation window.
Figure 1-6 Read Tags Window
• Click Start Inventory to initiate an on-demand scan on the connected antennas that are enabled.
• Click Stop Inventory to stop the inventory operation.
• Select the Clear Tag List check box to clear the current tag list.
The list of tags appears in a table with the following attributes for each tag:
• EPC Id: Unique tag EPC ID.
• TagSeen Count: Number of times the tag is identified on the specific antenna.
• RSSI: Received Signal Strength Indication.
• Antenna Id: Antenna ID on which the tag is seen.
• FirstSeen time stamp: UTC time (in microseconds) when the tag was first seen.
• LastSeen time stamp: UTC time (in microseconds) when the tag was last seen.
NOTE Enable Java JRE support on the browser for this page to function properly.
NOTE For security reasons browsers may block the Read Tags page. Look for a pop window that can be hidden
behind the browser or at the bottom of the screen (the taskbar in Windows) and allow the applet to run.
NOTE With older browsers, when upgrading/downgrading the FX7500, close the browser and re-open it to clear
the old version of files cached. If the java cache for applets is on, clear the cached applet before starting
the browser to use the Read Tags page.

Zebra FX7500 Specifications

General

Interface	USB
Product color	White
LED indicators	Activity, Power, Status
Housing material	Aluminium, Metal, Plastic
Battery type	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84719000

Weight and Dimensions

Depth	43.2 mm
Width	149.9 mm
Height	195.6 mm
Weight	860 g
