Zebra Z4Mplus User Manual

76 Z4Mplus and Z6Mplus User Guide
Configuration
Configuration and Calibration Sequence
DELIMITER CHAR Press SELECT to make change.
Delimiter Character: Press MINUS (–) to move to the next
digit position, press PLUS (+) to increase the value of the
digit.
Default: 2C (comma)
Range: 00 to FF
Press SELECT to accept the change.
The delimiter character is a 2-digit hex value used as a
parameter place marker in
ZPL/ZPL II format instructions. See the ZPL II
Programming Guide Volume I for more information.
Selecting ZPL Mode
ZPL MODE Press SELECT to make change.
Selecting ZPL Mode: Press PLUS (+) or MINUS (–) to
display other choices.
Default: ZPL II
Selections: ZPL II, ZPL
Press SELECT to accept the change.
The printer remains in the selected mode until it is changed
by this front panel instruction or by using a ZPL/ZPL II
command. The printer accepts label formats written in either
ZPL or ZPL II. This eliminates the need to rewrite any ZPL
formats you already have. See the ZPL II Programming
Guide Volume II for more information on the differences
between ZPL and ZPL II.
Display Shows Action/Explanation

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
