66 Z4Mplus and Z6Mplus User Guide
Configuration
Configuration and Calibration Sequence
LIST IMAGES Press SELECT to select.
List Images: Press PLUS (+) to print a label listing all of
the available images.
This selection is used to print a label that lists all of the
images currently stored in the printer’s RAM, FLASH
memory, optional EPROM, or optional memory card.
LIST FORMATS Press SELECT to select.
List Formats: Press PLUS (+) to print a label listing all of
the available formats.
This selection is used to print a label that lists all of the
formats currently stored in the printer’s RAM, FLASH
memory, optional EPROM, or optional memory card.
LIST SETUP Press SELECT to select.
List Setup: Press PLUS (+) to print a label listing the
current printer configuration.
This selection is used to print a label that lists the current
printer configuration information. (Same as Cancel Self Test
on page 109.)
LIST ALL Press SELECT to select.
List All: Press PLUS (+) to print a label listing all of the
available fonts, bar codes, images, formats, and the current
printer configuration.
This selection is used to print a label that lists the five
previous selections, as described.
Display Shows Action/Explanation

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
