Zebra Z4Mplus User Manual

Configuration
Configuration and Calibration Sequence
Z4Mplus and Z6Mplus User Guide 67
FORMAT CARD
A B
Initialize Memory Card
Caution • Perform this operation only when it is necessary
to erase all previously stored information from the optional
memory card. Press PLUS (+) to bypass this function.
Press SELECT to make change. If your printer is set to
require a password, you are prompted to enter the password.
Enter the password and then press SELECT.
Press the PLUS (+) to select B memory (PCMCIA card) or
press MINUS (–) to select the A memory (internal compact
flash).
The front panel LCD asks ARE YOU SURE?.
Press PLUS (+) YES to begin initialization.
or
Press MINUS (–) No to cancel the request and return to the
INITIALIZE CARD prompt.
FORMATTING CARD displays. When formatting is
complete, FORMAT CARD displays.
Press SELECT to accept the change.
Depending on the amount of memory in the memory card,
initialization may take up to three minutes to complete.
Display Shows Action/Explanation

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
