Zener MSC-3 User Manual

IM00120
5
IM00120
MSC-3 Instruction Manual
E
F
B
C
A
D
G
G
Bolt
Diameter
Bolt
Diameter
Chassis B (15 - 40 Amps)
CAUTION
Allow 75mm above, below and either side of the enclosure for ventilation
Model Enclosure type Dimensions - tolerance +/- 1.0mm Weight
without
choke
Weight
with choke
A B C D E F G
MSC-3*3
MSC-3*5
MSC-3*7
MSC-3*11
Chassis A
IP30 / NEMA 1
(No DC Choke)
248mm
9.8”
102mm
4”
237mm
9.3”
208mm
8.2”
32mm
1.3”
230mm
9.1”
6mm
0.25”
3.5Kg
8lbs
MSC-3*3
MSC-3*5
MSC-3*7
MSC-3*11
Chassis A
IP30 / NEMA 1
(With DC Choke)
248mm
9.8”
102mm
4”
309mm
12.2”
208mm
8.2”
32mm
1.3”
230mm
9.1”
6mm
0.25”
7.2Kg
16lbs
MSC-3*3
MSC-3*5
MSC-3*7
MSC-3*11
Chassis A
IP66 / NEMA 4
310mm
12.2”
190mm
7.5”
236mm
9.3”
250mm
9.8”
108mm
4.3”
287mm
11.3”
6mm
0.25”
5.7Kg
13lbs
8.6Kg
19lbs
MSC-3*15
MSC-3*23
MSC-3*30
Chassis B
All types
459mm
18.1”
234mm
9.2”
243mm
9.6”
400mm
15.8”
130mm
5.1”
436mm
17.1”
6mm
0.25”
17.7Kg
38lbs
22.9Kg
51lbs
MSC-3*40 Chassis B
All types
459mm
18.1”
234mm
9.2”
243mm
9.6”
400mm
15.8”
130mm
5.1”
436mm
17.1”
6mm
0.25”
24.8Kg
55lbs
* L, R or J to specify supply voltage - see page 60 for details
CAUTION
All MSC-3Jxx (600VAC) models must be used with DC bus choke.
