ZXR10 2920/2928/2952
(V1.0) Access Switch User Manual Volume I
274 Confidential and Proprietary Information of ZTE CORPORATION
FIGURE 56 PVLAN INFORMATION
f Table 431 defines parameters shown in Figure 56.
TABLE 431 PVLAN PARAMETERS DESCRIPTION
Parameters Description
PVlan Session Pvlan session
Promiscuous Port Prmoiscuous port
Isolated Port Isolated port
Isolated Trunk Isolated trunk
2. Click the catalog tree in the left of the system main page
Configuration > PVLAN > Pvlan Configure to open the
PVLAN configuration page, as shown in
Figure 57.
