ACS2000 User manual 2UEA001270 Rev. F 2-11 (28)
Chapter 2 - Power electronics and cabinet features
Figure 2-9 Grounding the drive
Legend
1 GROUND SW RELEASED pilot light
2 Grounding switch handle - grounded (OFF) position
3 Grounding switch handle - ungrounded (ON) position
123
Grounded O-(OFF)
position
Ungrounded I -(ON)
position
O
I
O
I
