Chapter 3 - Control system
3.3.3.3 IOEC4 (A1621) analog inputs
Table 3-10 Optional analog input signal allocation
3.3.3.4 IOEC4 (A1621) analog outputs
Table 3-11 Optional analog output signal allocation
Terminal Channel Default setting Par. Group
X31-1 +10 V
0 V
Internal supply voltage —
X32-1
X31-2 AI1+
AI1-
Motor winding U2 temperature
X32-2
X31-3 AI2+
AI2-
Motor winding V2 temperature
X32-3
X31-4 AI3+
AI3-
Motor winding W2 temperature
X32-4
X31-5 AI4+
AI4-
Reserved
X32-5
Remote speed supply
output specifications
Output voltage 10 V
Available output current 5mA
Analog input resolution 10 bit
Voltage mode Current mode
Signal range
0...10 V
Signal range
0...20mA
Load impedance
250 kΩ
Load impedance
105 Ω
S1
S2
AI1 20m
A
AI1 10 V
AI2 20m
A
AI2 10 V
OFF ON
AI3 20m
A
AI3 10 V
AI4 20m
A
AI4 10 V
S1
S2
AI1 20mA
AI1 10 V
AI2 20mA
AI2 10 V
OFF ON
AI3 20mA
AI3 10 V
AI4 20mA
AI4 10 V
Terminal Channel Default setting Par. Group
X31-6 AO1+
AO1-
Freely programmable
X32-6
X31-7 AO2+
AO2-
Freely programmable
X32-7
Analog output resolution 12 bit
Signal level
0...20mA
Load impedance
250 Ω
