Actual signals and parameters 227
3408 SIGNAL2
PARAM
Selects the second signal to be displayed on the control
panel in the Output mode. See parameter 3401 SIGNAL1
PARAM.
104
0, 101…178 Parameter index in group 01 OPERATING DATA. For
example, 102 = 0102 SPEED. If value is set to 0, no signal
is selected.
1 = 1
3409 SIGNAL2 MIN Defines the minimum value for the signal selected by
parameter 3408 SIGNAL2 PARAM. See parameter 3402
SIGNAL1 MIN.
-
x…x Setting range depends on parameter 3408 SIGNAL2
PARAM setting.
-
3410 SIGNAL2 MAX Defines the maximum value for the signal selected by
parameter 3408 SIGNAL2 PARAM. See parameter 3402
SIGNAL1 MIN.
-
x…x Setting range depends on parameter 3408 SIGNAL2
PARAM setting.
-
3411 OUTPUT2 DSP
FORM
Defines the format for the displayed signal selected by
parameter 3408 SIGNAL2 PARAM.
DIRECT
See parameter 3404 OUTPUT1 DSP FORM.-
3412 OUTPUT2
UNIT
Selects the unit for the displayed signal selected by
parameter 3408 SIGNAL2 PARAM.
-
See parameter 3405 OUTPUT1 UNIT.-
3413 OUTPUT2 MIN Sets the minimum display value for the signal selected by
parameter 3408 SIGNAL2 PARAM. See parameter 3402
SIGNAL1 MIN.
-
x…x Setting range depends on parameter 3408 SIGNAL2
PARAM setting.
-
34
14 OUTPUT2
MAX
Sets the maximum display value for the signal selected by
parameter 3408 SIGNAL2 PARAM. See parameter 3402
SIGNAL1 MIN.
-
x…x Setting range depends on parameter 3408 SIGNAL2
PARAM setting.
-
3415 SIGNAL3
PARAM
Selects the third signal to be displayed on the control panel
in the Output mode. See parameter 3401 SIGNAL1
PARAM.
105
0, 101…178 Parameter index in group 01 OPERATING DATA. For
example, 102 = 0102 SPEED. If value is set to 0, no signal
is selected.
1 = 1
3416 SIGNAL3 MIN Defines the minimum value for the signal selected by
parameter 3415 SIGNAL3 PARAM. See parameter 3402
SIGNAL1 MIN.
-
x…x Setting range depends on parameter 3415 SIGNAL3
PARAM setting.
-
3417 SIGNAL3 MAX Defines the maximum value for the signal selected by
parameter 3415 SIGNAL3 PARAM. See parameter 3402
SIGNAL1 MIN.
-
x…x Setting range depends on parameter 3415 SIGNAL3
PARAM setting.
-
3418 OUTPUT3 DSP
FORM
Defines the format for the displayed signal selected by
parameter 3415 SIGNAL3 PARAM.
DIRECT
All parameters
No. Name/Value Description Def/FbEq
