Parameters 199
30.22 Max torque 2 source Defines the source of the maximum torque limit for the
drive (in percent of nominal motor torque) when
• the source selected by parameter 30.18 Tor q lim se l is
1, or
• 30.18 is set to Torque limit set 2.
See diagram at 30.18 Tor q l im sel.
Note: Any negative values received from the selected
source are inverted.
WARNING! In torque control mode (vector motor
control) only.
Maximum
torque 2
Zero None. 0
AI1 scaled 12.12 AI1 scaled value (see page 127). 1
AI2 scaled 12.22 AI2 scaled value (see page 129). 2
PID 40.01 Process PID output actual (output of the process
PID controller).
15
Maximum torque 2 30.24 Maximum torque 2.16
Other Source selection (see Terms and abbreviations). -
30.23 Minimum torque 2 Defines the minimum torque limit for the drive (in percent
of nominal motor torque) when
• the source selected by 30.18 Torq lim sel is 1, or
• 30.18 is set to Torque limit set 2
and
• 30.21 Min torque 2 source is set to Minimum torque 2.
See diagram at 30.18 Tor q l im sel.
WARNING! In torque control mode (vector motor
control) only.
-300.0%
-1600.0…0.0% Minimum torque limit 2. See par.
46.03
30.24 Maximum torque 2 Defines the maximum torque limit for the drive (in percent
of nominal motor torque) when
The limit is effective when
• the source selected by 30.18 Torq lim sel is 1, or
• 30.18 is set to
Torque limit set 2
and
• 30.22 Max torque 2 source is set to Maximum torque
2.
See diagram at 30.18 Tor q l im sel.
WARNING! In torque control mode (vector motor
control) only.
300.0%
0.0…1600.0% Maximum torque limit 2. See par.
46.03
30.26 Power motoring limit Defines the maximum allowed power fed by the inverter to
the motor in percent of nominal motor power.
300.00%
0.00…600.00% Maximum motoring power. 1 = 1%
30.27 Power generating limit Defines the maximum allowed power fed by the motor to
the inverter in percent of nominal motor power.
-300.00%
-600.00…0.00% Maximum generating power. 1 = 1%
No. Name/Value Description Default
FbEq 16
