Parameters 207
Both Action is taken whenever the signal falls below its low limit
or rises above its high limit.
5
Abs both Action is taken whenever the absolute value of the signal
falls below its (absolute) low limit or rises above its
(absolute) high limit.
6
32.06 Supervision 1 action Selects whether the drive generates a fault, warning or
neither when the value monitored by signal supervision 1
exceeds its limits.
Note: This parameter does not affect the status indicated
by 32.01 Supervision status.
No action
No action No warning or fault generated. 0
Warning Warning A8B0 Signal supervision is generated. 1
Fault The drive trips on fault 80B0 Signal supervision.2
Fault if running The drive trips on fault 80B0 Signal supervision if running. 3
32.07 Supervision 1 signal Selects the signal to be monitored by signal supervision
function 1.
Frequency
Zero None. 0
Speed 01.01 Motor speed used.1
Frequency 01.06 Output frequency.3
Current 01.07 Motor current.4
Torque 01.10 Motor torque. 6
DC voltage 01.11 DC voltage.7
Output power 01.14 Output power.8
AI1 12.11 AI1 actual value.9
AI2 12.21 AI2 actual value.10
Speed ref ramp in 23.01 Speed ref ramp input.18
Speed ref ramp out 23.02 Speed ref ramp output.19
Speed ref used 24.01 Used speed reference.20
Torque ref used 26.02 Torque reference used.21
Freq ref used 28.02
Frequency ref ramp output.22
Inverter temperature 05.11 Inverter temperature.23
Process PID output 40.01 Process PID output actual.24
Process PID feedback 40.02 Process PID feedback actual.25
Process PID setpoint 40.03 Process PID setpoint actual.26
Process PID deviation 40.04 Process PID deviation actual.27
Other Source selection (see Terms and abbreviations). -
32.08 Supervision 1 filter
time
Defines a filter time constant for the signal monitored by
signal supervision 1.
0.000 s
0.000 … 30.000 s Signal filter time. 1000 = 1 s
32.09 Supervision 1 low Defines the lower limit for signal supervision 1. 0.00
-21474830.00…
21474830.00
Low limit. -
No. Name/Value Description Default
FbEq 16
