AO2000 CONTINUOUS GAS ANALYZERS | OI/AO2000-EN REV. B 23
Description
Gas analyzers for the 'Safety Concept'
Gas analyzers for the 'Safety Concept' consist of analyzer modules
• Limas11 IR, Uras26 (see page 28) in the version with safety cell and
purged sample cell windows,
• Caldos25, Caldos27, Magnos206 (see page 30) in the version with direct
sample chamber connection and purged thermostat room,
each mounted in the 19-inch housing (Model AO2020) or wall-mounted
housing (Model AO2040).
The purge gas flow monitoring (see page 32) is a constituent part of the
'Safety Concept', including a control and evaluation, it is fully integrated into
the gas analyzer.
Design
The gas analyzer consists of the central unit (system housing with display
and operator control unit, power supply unit and electronics module) and
the analyzer module.
The analyzer module is installed in the central unit or in a separate housing.
The version satisfies the provisions of the European Directive 2014/34/EU
(ATEX Directive). It is designed to EN 60079-15 and EN 60079-2.
NOTE
The Declaration of Conformity can be found on the DVD-ROM "Software
tools and technical documentation" which is delivered together with the gas
analyzer.
The temperature class of the analyzer is T4.
The measurement function of the gas analyzers was not checked for suita-
bility for influencing of other devices in hazardous areas.
Remark: Non-flammable gas is a gas mixture with a proportion of flammable
components which is always – therefore even in the event of an error – smaller
than the lower explosive limit (LEL).
Designation
II 3G Ex nA pyb II T4 Gc
