Section D Graphic Display
D-33
Border/Fill color Click mouse on color field or press TAB key repeatedly until focus is on
the color field, then press S
PACEBAR.
It is possible to change the border and fill color settings for the dynamic
graphic object. The setting of the desired colors is made out with the color
selection parameter window (see page D-13, Color selection). With the
setting invisible, the border or area is displayed transparent, with Original
colors, the colors of the static graphic object are used.
If the state of the graphic object is influenced by messages, then, in the
second color dialog (M
ESSAGE COLORS) the object can be configured to
take on colors from the messages it depends on (see below)
D
ISPLAY Switch to the graphic display. Operative only with certain dynamic graphic
objects.
Object name → Click field → F2 Function key,
→ Outputs the names of the static graphic objects that are not yet in use.
→ Select and OK,
→ Name of selected graphic object is shown in this field.
or
→ Click the desired field under Object name
→ Use D
ISPLAY to change to the graphic display,
→ Select existing or newly created static graphic object which is not yet
in use
→ Return to parameter definition via → Edit → Return to object
→ Name of the graphic object is entered in the field (If a static graphic
object without a specified name is selected, this object is automatically
assigned a system-generated name.)
