Section C Standard Displays
C-10
C 2.3.1 Enter display names
→ Select overview display segment → right mouse button → Select
→ Select display type and display name from the selector list
→ OK
The display selection list is opened via the menu item Select in the shortcut menu or
on pressing the function key F2. All displays and logs configured so far are listed ac-
cording to display types in the window which now appears.
Select an overview display segment from the configuration mask. The display name (if known)
can be entered directly or can be selected from the display selector list.
Abbreviations in the display selector list
DCL_D-OS Disturbance course log
FGR Free graphic display
GRP Group display
OPL Operator plant log
SFCP Sequential function chart display
SSL1 Signal sequence log, directly on printer
SSLN Signal sequence log, manually
TR_D-OS Trend display
TS_D-OS Time scheduler display
C 2.3.2 Plausibility check
The overview display is checked for syntactical and contextual errors. If errors are found, they
are displayed in a list. Implausible display and log names are shown in red in the configuration
mask, the plausible ones are shown in black.
