Section D Graphic Display
D-91
D 8.2 Simulation
→View → Simulation
→Switch simulation on or off and select the simulation speed.
→All self-animated graphic objects are shown in the graphic display with the chosen
simulation attributes.
When in View the simulation attributes come into play for all self-animated objects; when the
graphic editor is in View the simulation attributes can also be modified.
D8.3 Redraw
→View → Redraw
→Graphic is redisplayed on the screen with no change to the zoom level.
The graphic is reconstructed. This is necessary, if the current display of the graphic on the screen
does not correspond to the real graphic (parts of the frame may, for example, have been left
behind).
D 8.4 Zoom
→View → Zoom
→Select zoom level 1 to 4 or Overview
→Display the graphic with a dashed rectangle
→Use the mouse to move the rectangle over the desired region of the graphic
→Click mouse, and that region will be displayed at the selected zoom level
A graphic display is usually displayed with Zoom switched off (Zoom 1-fold) as a whole graphic in
the draw area. For easier editing it is possible to display a section of the graphic with 2-, 3- or 4-
fold enlargement. The selected zoom level is indicated in the toolbox under D
ISPLAY. After
selection of the zoom level the whole graphic display is shown, and a dashed rectangle
superimposed for selecting the desired visible region.
With Visible region or a right mouse-click it is possible to display a different region of the screen.
The Overview function shows an area corresponding to 9 x the drawing size. The actual
drawing area is displayed in the center and is marked with a border. This function enables
objects located completely or partially outside the applicable draw area to be displayed and
identified.
