Section C Standard Displays
C-13
C 3.3.1 Enter a tag
→ Select group display segment → Call shortcut menu using right mouse button →
Select
→ Select function type and name from the selection list → OK
The tag selection list opens via the menu item Select in the shortcut menu or on
pressing the function key F2. All tags configured so far are listed acc. to function types in
the window which now appears. For abbreviations in the tag selection list see Engi-
neering Reference Manual, Functions and Function Blocks.
Select a group display segment from the configuration mask. The tag name (if known) can be
entered directly or can be selected from the selector list.
C 3.3.2 Plausibility check
The group display is checked for syntactical and contextual errors. If errors are found, they are
displayed in a list. Implausible tags are displayed in red in the configuration mask, the plausible
ones are displayed in black.
