Section D Graphic Display
D-25
The dynamic graphic objects most commonly used for plant operation actions in graphic
displays are the following: selection fields, buttons, button fields and radio button fields. These
operation objects can be configured to trigger the following actions in DigiVis:
• Call up a tag allocation faceplate,
• Switch to any other display,
• Write a pre-determined value to a variable,
• Write an operation value to a variable,
• Acknowledge a message.
These operation actions can also be initiated by a display object.
In DigiVis, when a graphic display is updated, all dynamic objects are placed in front (on top) of
any static display elements. This can be altered by making the static elements part of a
dynamic object and designating them as foreground or background components within that
object. Such grouping makes it possible, for example, to display scale markings on a bar graph.
D 5.1 Create a dynamic graphic object
→Animate → Select type of dynamic graphic object,
→For a new bar graph, alphanumeric display, selection field, button, button field, radio
button or trend window click mouse to indicate the desired object position.
→Parameter definition dialog is displayed
The editing functions under the Edit menu are only partly usable on dynamic graphic
objects.
The system automatically assigns a name for each new dynamic object, and the name is
shown in the general section of the parameter dialog. It can be changed by the user at any
time. Object names must be unique within a graphic display.
D 5.2 Delete dynamic object
→Select dynamic graphic object → Edit → Delete.
→Select dynamic graphic object → DELETE.
