D 8.5 Visible region
→View → Select visible region
→Graphic is displayed with a dashed rectangle,
→Use mouse to move rectangle and position it over the desired region,
→Click mouse to display this region with the selected zoom level.
→Click right mouse button
→Graphic is displayed with a dashed rectangle,
→Use mouse to move rectangle and position it over the desired region,
→Click mouse to display this region with the selected zoom level.
→View → Select visible region
→Position cursor within the visible draw field,
→Press C
TRL +ARROW KEYS → SPACEBAR
→The displayed graphic is moved a fixed distance in the direction of the arrow,
depending on the zoom level selected, and is redrawn.
In order to select a display region (for zoom level > 1), Select visible region makes a rectangle
appear in the draw field . This rectangle can be moved around the draw area and, following a
mouse click or a press of the S
PACEBAR, the area located underneath it will be displayed enlarged
by the selected zoom level.
