ABB Freelance 2000 - Graphic Editor Interface

Section D Graphic Display
D-6
D 2 Graphic Editor Interface
The graphic area consists of the title line, the menu line, the draw area, the status line and the
toolbox.
Title line
Menu line
Draw area with grid
switched on, crosshairs
and toolbox.
Status line with
user name
