Section D Graphic Display
D-55
Color table
By configuring a maximum of 3 binary variables, the graphic symbol can be displayed in up to 8
states. For each of these states, a static graphic object and a color combination is specified
(see also Page D-32, Display tab)
Object name → Click field → F2 Function key,
→ Outputs the names of the static graphic objects that are not yet in use.
→ Select and OK,
→ Name of selected graphic object is shown in this field.
or
→ Click the desired field under Object name
→ Use D
ISPLAY to change to the graphic display,
→ Select existing or newly created static graphic object which is not yet
in use
→ Return to parameter definition via → Edit → Return to object
→ Name of the graphic object is entered in the field (If a static graphic
object without a specified name is selected, this object is automatically
assigned a system-generated name.)
D 5.19 Self-animated object
→Animate → Self-animated object
→Fill out the parameter-definition masks,
→Press the D
ISPLAY button in the color table mask,
→Select or create graphic objects in the graphic display,
→Return to parameter mask via → Animate → Return to dynamic object,
→OK.
Up to 8 static graphic objects will be displayed in turn for 125 or 250 ms each.
When a graphic symbol is moved, all associated elements are moved together.
If the View all box is ticked in the Display parameters mask, all the elements of the selected
object that are being used will appear in the display, and—when selected—will be surrounded
by a construction frame.
A self-animated object is configured using the parameters on the Bit allocation, Display and
General tabs.
